Focus Sim Racing Side Mount Pro + Moza Front Mount Bundle

Side Mount Pro + MOZA Front Mount Bundle

The Focus Sim Racing Side Mount Pro + MOZA Front Mount Bundle combines our Modular Side Mount Pro with the compatible MOZA front mounting plate to create a complete mounting solution for select MOZA direct drive wheelbases.

Rather than using a traditional wheel deck or piecing together separate mounting components, the wheelbase attaches directly to the Focus front plate while the Modular Side Mount Pro connects the complete assembly to your chassis uprights. The result is a rigid, adjustable, and clean front-mounted installation designed around modern direct drive hardware.

The complete system supports chassis mounting widths from 580mm to 660mm and includes 45mm of integrated fore-aft adjustment for fine-tuning wheel position.

Compatible MOZA Wheelbases

The included Focus front mounting plate is designed for compatible MOZA direct drive wheelbases.

• MOZA R9
• MOZA R12
• MOZA R16
• MOZA R21
• MOZA R21 Ultra
• MOZA R25 Ultra

Modular Side Mount Pro + Focus MOZA Front Plate

This bundle uses the same Modular Side Mount Pro found throughout the Focus Side Mount Pro ecosystem. The wheelbase-specific Focus front plate mounts between the Side Mount Pro arms, allowing compatible MOZA wheelbases to be front mounted directly to the system.

• Modular Side Mount Pro provides the chassis mounting structure
• MOZA Front Mounting Plate provides the wheelbase-specific mounting interface
• Eliminates the need for a traditional bottom-mounted wheel deck
• No custom fabrication required for listed compatible wheelbases
• Creates a clean, purpose-built direct drive mounting solution

Because the Side Mount Pro uses a modular front plate system, the core mounting assembly can also support other wheelbase platforms when paired with the appropriate compatible Focus front mounting plate.

580mm–660mm Chassis Mounting Width

When the Modular Side Mount Pro is used with a Focus front mounting plate, the complete assembly supports chassis mounting locations from 580mm to 660mm apart.

• Minimum Chassis Mounting Width: 580mm
• Maximum Chassis Mounting Width: 660mm
• Designed for Focus Sim Racing chassis and compatible aluminum profile rigs
• May fit chassis from other manufacturers when the upright spacing and extrusion layout fall within the supported range

Because chassis dimensions and upright layouts vary between manufacturers, we recommend measuring the distance between your mounting locations before ordering.

45mm Integrated Fore-Aft Adjustment

The Side Mount Pro includes 45mm of front-to-back adjustment, allowing the wheelbase position to be fine-tuned independently of the chassis uprights.

• 45mm of integrated fore-aft adjustment
• Move the wheelbase closer to or farther from the driver
• Fine-tune steering position without moving the seat or chassis uprights
• Useful for adapting the simulator to different drivers and seating positions
• Slotted mounting points lock securely once the desired position is set

Purpose-Built Front Mounting

Compatible MOZA wheelbases attach directly to the included Focus front mounting plate, creating a rigid connection between the wheelbase and Side Mount Pro structure.

• Direct connection between the wheelbase and Focus front plate
• Designed for high-torque direct drive wheelbases
• Eliminates the need for a traditional bottom-mounted wheel deck
• Keeps the mounting structure compact around the wheelbase
• Provides clear access around the sides and underside of the base

Purpose-Built Construction

The Side Mount Pro combines aluminum and steel components to create a rigid connection between the wheelbase and chassis.

• 10mm CNC-milled aluminum chassis brackets provide a strong, precise connection to the chassis uprights
• 5mm laser-cut steel wheelbase brackets form the structural connection between the Side Mount Pro arms and front plate assembly
• Steel Focus MOZA front mounting plate provides the wheelbase-specific mounting interface
• Aluminum extrusion side arms connect the complete assembly
• Major components feature a durable black powder-coated finish

Fitment & Compatibility

• Designed for listed MOZA direct drive wheelbases
• Uses the Focus Modular Side Mount Pro
• Includes the compatible Focus MOZA front mounting plate
• Compatible Chassis Mounting Width: 580mm–660mm
• Front-to-Back Adjustment: 45mm
• Designed for aluminum profile sim racing chassis
• May fit compatible chassis from other manufacturers when mounting width and extrusion layout fall within the supported range

We recommend confirming both your MOZA wheelbase model and chassis mounting width before ordering.

Key Features

• Complete Side Mount Pro and MOZA front plate bundle
• Compatible with select MOZA R9, R12, R16, R21, R21 Ultra, and R25 Ultra wheelbases
• 580mm–660mm chassis mounting-width range
• 45mm integrated fore-aft adjustment
• 10mm CNC-milled aluminum chassis brackets
• 5mm laser-cut steel wheelbase brackets
• Dedicated steel MOZA front mounting plate
• Modular front plate architecture
• Designed for high-torque direct drive systems
• Black powder-coated finish

What's Included

• 2 × Aluminum extrusion Side Mount Pro arms
• 2 × 10mm CNC-milled aluminum chassis brackets
• 2 × 5mm laser-cut steel wheelbase brackets
• 1 × Focus MOZA front mounting plate
• Complete mounting hardware including bolts and T-nuts

One System, Built Around Your MOZA Wheelbase

This bundle takes the Modular Side Mount Pro and adds the MOZA-specific front plate required for compatible wheelbases. You get the rigidity and adjustment of the Side Mount Pro with a mounting interface designed specifically around your MOZA hardware.

Rigid, adjustable, and ready for MOZA.
