Focus Sim Racing Side Mount Pro + Front Mount Bundle for Simucube & VRS

Side Mount Pro + Front Mount Bundle for Simucube & VRS

The Focus Sim Racing Side Mount Pro + Front Mount Bundle combines our Modular Side Mount Pro with the compatible Simucube/VRS front mounting plate to create a complete mounting solution for select Simucube and VRS direct drive wheelbases.

Rather than requiring a separate wheel deck or additional adapters, the wheelbase mounts directly to the Focus front plate while the Modular Side Mount Pro connects the complete assembly to your chassis uprights. The result is a rigid, adjustable, and clean front-mounted installation designed around high-performance direct drive hardware.

The complete system supports chassis mounting widths from 580mm to 660mm and includes 45mm of integrated fore-aft adjustment for fine-tuning wheel position.

Compatible Wheelbases

The included Focus front mounting plate is designed for compatible Simucube and VRS wheelbases.

• Simucube 2 Sport
• Simucube 2 Pro
• Simucube 2 Ultimate
• Simucube 3 Sport
• Simucube 3 Pro
• Simucube 3 Ultimate
• VRS DFP15
• VRS DFP20
• VRS uDFP20

Modular Side Mount Pro + Focus Front Plate

This bundle uses the same Modular Side Mount Pro found in the Focus Side Mount Pro ecosystem. Instead of a dedicated wheelbase-specific side bracket, the Modular Edition accepts a Focus front mounting plate designed around the wheelbase mounting interface.

• Modular Side Mount Pro provides the chassis mounting structure
• Simucube/VRS Front Mounting Plate provides the wheelbase-specific mounting interface
• Allows the Side Mount Pro to support multiple wheelbase platforms through interchangeable Focus front plates
• No custom fabrication required for listed compatible wheelbases
• Creates a clean, purpose-built installation without a traditional wheel deck

This modular architecture also means that if you change wheelbase platforms in the future, the Side Mount Pro itself can remain in place when a compatible Focus front mounting plate is available for the new wheelbase.

580mm–660mm Chassis Mounting Width

When the Modular Side Mount Pro is used with a Focus front mounting plate, the complete assembly supports chassis mounting locations from 580mm to 660mm apart.

• Minimum Chassis Mounting Width: 580mm
• Maximum Chassis Mounting Width: 660mm
• Designed for Focus Sim Racing chassis and compatible aluminum profile rigs
• May fit chassis from other manufacturers when the upright spacing and extrusion layout fall within the supported range

Because chassis dimensions and upright layouts vary between manufacturers, we recommend measuring the distance between your mounting locations before ordering.

45mm Integrated Fore-Aft Adjustment

The Side Mount Pro includes 45mm of front-to-back adjustment, allowing the wheelbase position to be fine-tuned independently of the chassis uprights.

• 45mm of integrated fore-aft adjustment
• Move the wheelbase closer to or farther from the driver
• Fine-tune steering position without moving the seat or chassis uprights
• Useful for adapting the simulator to different drivers and seating positions
• Slotted mounting points lock securely once the desired position is set

Purpose-Built Front Mounting

Compatible Simucube and VRS wheelbases are designed with a front mounting interface, allowing the wheelbase to attach directly to the included steel front plate.

• Direct connection between the wheelbase and Focus front plate
• Rigid mounting solution for high-torque direct drive wheelbases
• Eliminates the need for a traditional bottom-mounted wheel deck
• Keeps the mounting structure compact around the wheelbase
• Provides clear access around the sides and underside of the base

Purpose-Built Construction

The Side Mount Pro combines aluminum and steel components to place rigidity where steering loads are transferred into the chassis.

• 10mm CNC-milled aluminum chassis brackets provide a strong, precise connection to the chassis uprights
• 5mm laser-cut steel wheelbase brackets form the structural connection between the Side Mount Pro arms and front plate assembly
• Steel Focus front mounting plate provides the wheelbase-specific mounting interface
• Aluminum extrusion side arms connect the complete assembly
• Major components feature a durable black powder-coated finish

Fitment & Compatibility

• Designed for Simucube 2, Simucube 3, and listed VRS wheelbases
• Uses the Focus Modular Side Mount Pro
• Includes the compatible Focus Simucube/VRS front mounting plate
• Compatible Chassis Mounting Width: 580mm–660mm
• Front-to-Back Adjustment: 45mm
• Designed for aluminum profile sim racing chassis
• May fit compatible chassis from other manufacturers when mounting width and extrusion layout fall within the supported range

We recommend confirming both your wheelbase model and chassis mounting width before ordering.

Key Features

• Complete Side Mount Pro and front plate bundle
• Compatible with select Simucube 2, Simucube 3, and VRS wheelbases
• 580mm–660mm chassis mounting-width range
• 45mm integrated fore-aft adjustment
• 10mm CNC-milled aluminum chassis brackets
• 5mm laser-cut steel wheelbase brackets
• Dedicated steel Simucube/VRS front mounting plate
• Modular front plate architecture
• Designed for high-torque direct drive systems
• Black powder-coated finish

What's Included

• 2 × Aluminum extrusion Side Mount Pro arms
• 2 × 10mm CNC-milled aluminum chassis brackets
• 2 × 5mm laser-cut steel wheelbase brackets
• 1 × Focus Simucube/VRS front mounting plate
• Complete mounting hardware including bolts and T-nuts

One System, Built Around Your Wheelbase

This bundle takes the Modular Side Mount Pro and adds the wheelbase-specific front plate required for compatible Simucube and VRS hardware. You get the rigidity and adjustment of the Side Mount Pro with a mounting interface designed specifically around your wheelbase.

Rigid, adjustable, and ready for Simucube or VRS.
